## Cooling and heating degree days with CDO

###### Recently at work, I had to calculate cooling and heating degree days per annum for future climate projections. Eurostat provides both metrics only for the past. I found a convenient option to calculate both using a bash script and CDO for flexible base/threshold temperatures. This post presents my solution without any further ado.

Heating degree days for a certain day are defined as `HDD(i) = b - t(i) if t(i) < b`, where b is the base temperature and t(i) is the temperature at the selected date. Cooling degree days are defined as `CDD(i) = t(i) - b if t(i) > b`. You may sum both to the required timescale, e.g., monthly, seasonal, or yearly. The bash script below is commented to explain the relevant steps.

``````K=273.15

# Calculates annual Heating Degree Days (HDD)
# \$1 Base temperature in Celsius
# \$2 Temperature data in Kelvin (K)
# \$3 Name of the output
function hdd {
local threshold=\${1-}
local file=\${2-}
local path=\${3:-}

# HDD(t, x) = threshold - file(t, x) if file(t, x) < threshold
# -yearsum := Calculate yearly sum of HDDs
# -addc,"\$threshold" -mulc,-1 := threshold - file(t, x) = threshold + (-1 * file(t, x))
# -setvrange,"\$(bc <<<"-1 * \$K"),\$threshold" := if file(t, x) < threshold; set each value smaller than absolute zero
# OR greater than threshold to missing
# -subc,"\$K" := Convert Kelvin to Celsius
echo "HDD... \$file to \$path"
cdo \
--timestat_date first \
-yearsum \
-setvrange,"\$(bc <<<"-1 * \$K"),\$threshold" \
-subc,"\$K" \
"\$file" "\$path" >/dev/null 2>&1
}

# Calculates annual Cooling Degree Days (HDD)
# \$1 Base temperature in Celsius
# \$2 Temperature data in Kelvin (K)
# \$3 Name of the output
function cdd {
local threshold=\${1-}
local file=\${2-}
local path=\${3:-}

# CDD(t, x) = file(t, x) - threshold if file(t, x) > threshold
# -yearsum := Calculate yearly sum of CDDs
# -subc,"\$threshold" := file(t, x) - threshold
# -setrtomiss,"\$(bc <<<"-1 * \$K"),\$threshold" := if file(t, x) > threshold; set each value smaller than threshold
# AND greater than absolute zero to missing
# -subc,"\$K" := Convert Kelvin to Celsius
echo "CDD... \$file to \$path"
cdo \
--timestat_date first \
-yearsum \
-subc,"\$threshold" \
-setrtomiss,"\$(bc <<<"-1 * \$K"),\$threshold" \
-subc,"\$K" \
"\$file" "\$path" >/dev/null 2>&1
}
``````

In my case, I use daily mean temperatures from the EURO-CORDEX dataset provided for download by the climate data store, a base temperature of 15℃ for HDDs, and 21℃ for CDDs.
